PMG G2 JX 280-26
4060 PSI (280 BAR) | 26 L/PM (6.6 GPM)
Category : Petrol pressure washer
PMG G2 JX 280-26
he PMG G2 JX 280-26 is a professional cold water petrol high-pressure cleaner designed for demanding daily cleaning applications. Delivering 4060 PSI (280 BAR) at 26 L/PM (1560 L/PH), it combines high-pressure performance with a powerful JX750 24 HP twin-cylinder petrol engine.
Built for professional operators, the PMG G2 JX 280-26 is suited to demanding clea
PMG G2 JX 280-26
he PMG G2 JX 280-26 is a professional cold water petrol high-pressure cleaner designed for demanding daily cleaning applications. Delivering 4060 PSI (280 BAR) at 26 L/PM (1560 L/PH), it combines high-pressure performance with a powerful JX750 24 HP twin-cylinder petrol engine.
Built for professional operators, the PMG G2 JX 280-26 is suited to demanding cleaning applications where high pressure and high water flow are required. The machine operates at 3200 RPM under load and features a 25 L petrol fuel tank, 12 V battery system and professional-grade pressure cleaning components. Jetwave classifies the unit for Professional – Daily use.
Key Features
- 4060 PSI / 280 BAR working pressure
- 26 L/PM / 1560 L/PH water flow
- JX750 twin-cylinder 4-stroke OHV petrol engine
- 24 HP / 17.89 kW maximum torque output
- 3200 RPM operating speed under load
- 25 L petrol fuel tank
- 12 V / 26 Ah / 280 CCA battery
- Maximum excess operating pressure of 5075 PSI / 350 BAR
- 60°C / 140°F maximum feed-water temperature
- 27 L/PM minimum feed-water volume
- 3/4" / 19 mm minimum inlet hose diameter
- IPX5 protection rating
- Professional – Daily duty cycle
- Nozzle size 065
- Compact professional machine design
- Designed for demanding commercial cleaning applications
Engine Specifications
The PMG G2 JX 280-26 uses a JX750 two-cylinder, four-stroke OHV petrol engine. Jetwave's technical manual specifies 17.89 kW / 24 HP maximum torque output at 3600 RPM and an operating speed of 3200 RPM under load.
- Engine: JX750
- Configuration: 2-cylinder
- Engine type: 4-stroke OHV
- Maximum torque output: 17.89 kW / 24 HP
- Operating speed under load: 3200 RPM
- Fuel: Unleaded petrol
- Fuel tank capacity: 25 L
- Battery: 12 V / 26 Ah / 280 CCA
High-Pressure Performance
The machine provides a combination of high operating pressure and high water flow for heavy-duty cleaning.
- Working pressure: 4060 PSI / 280 BAR / 28 MPa
- Flow rate: 26 L/PM / 1560 L/PH
- Maximum excess operating pressure: 5075 PSI / 350 BAR / 35 MPa
- Nozzle size: 065
- Maximum feed-water temperature: 60°C / 140°F
Water Connection
- Minimum feed volume: 27 L/PM / 1620 L/PH
- Maximum feed pressure: 101 PSI / 7 BAR / 0.7 MPa
- Minimum feed pressure: 4.35 PSI / 0.3 BAR / 0.03 MPa
- Minimum inlet hose diameter: 3/4" / 19 mm
- Maximum feed temperature: 60°C / 140°F
